Product Standards and Specifications

Womic Steel manufactures UNS S32750 stainless steel pipes strictly in accordance with the ASTM A789 standard, which covers seamless and welded ferritic/austenitic stainless steel tubing for general corrosion-resisting and high-temperature services.

- Applicable Standard: ASTM A789 / A789M
- Grade: UNS S32750 (commonly known as Super Duplex 2507)

Our production also aligns with NORSOK M-650, PED 2014/68/EU, and ISO 9001:2015 certification requirements, ensuring global compliance and acceptance.

Pipe Types and Production Range

Womic Steel offers both seamless and welded versions of ASTM A789 UNS S32750 stainless steel pipes.

- Outer Diameter: 1/4" (6.35mm) – 36" (914mm)
- Wall Thickness: SCH10S – SCH160 / customized
- Length: Up to 12 meters (custom lengths available)
- Form: Round, square, and rectangular sections

Custom cut-to-length and beveling services are also available on request.

Chemical Composition (per ASTM A789)

Chromium (Cr) : 24.0 – 26.0
Nickel (Ni) : 6.0 – 8.0
Molybdenum (Mo) : 3.0 – 5.0
Nitrogen (N) : 0.24 – 0.32
Manganese (Mn) : ≤ 1.2
Carbon (C) : ≤ 0.030
Phosphorus (P) : ≤ 0.035
Sulfur (S) : ≤ 0.020
Silicon (Si) : ≤ 0.8
Iron (Fe) : Balance

Mechanical Properties (per ASTM A789 for UNS S32750)

Tensile Strength (min) : 795 MPa (115 ksi)
Yield Strength (min, 0.2% offset) : 550 MPa (80 ksi)
Elongation (min) : 15%
Hardness (max) : 32 HRC or 310 HBW
Impact Toughness (Charpy) : ≥ 40 J at -46°C (optional by project spec)

Heat Treatment Process

Womic Steel performs solution annealing on all UNS S32750 stainless steel pipes:

- Heat Treatment Range: 1025°C – 1125°C
- Followed by rapid water quenching to ensure optimum corrosion resistance and ferrite-austenite balance.

Manufacturing Process and Inspection

Our advanced production process includes:

- Hot extrusion or cold drawing for seamless pipes
- TIG or laser welding for welded pipes
- In-line eddy current and ultrasonic inspection
- 100% PMI (Positive Material Identification)
- Hydrostatic testing at 1.5x design pressure
- Visual and dimensional inspection, intergranular corrosion testing, flattening and flaring tests

Certifications and Compliance

Womic Steel’s ASTM A789 S32750 pipes are delivered with full documentation and third-party inspection reports, including:

- EN 10204 3.1 / 3.2 certificates
- ISO 9001, PED, DNV, ABS, Lloyd’s Register, and NACE MR0175/ISO 15156 compliance

Application Fields

The excellent corrosion resistance and strength of UNS S32750 stainless steel pipes make them ideal for:

- Offshore and subsea oil & gas piping systems
- Desalination plants
- Chemical processing
- Marine environments
- High-pressure heat exchangers and condensers
- Power generation systems

Production Lead Time

Womic Steel maintains strong raw material inventory and advanced scheduling to provide:

- Production lead time: 15–30 days depending on order size
- Urgent delivery: Available with priority scheduling

Packaging & Transportation

Our ASTM A789 UNS S32750 pipes are packed with care to avoid surface damage and corrosion during transit:

- Packaging: Plastic end caps, HDPE film wrapping, seaworthy wooden cases or steel frame bundles
- Marking: Full traceability with heat number, size, standard, and Womic Steel branding
- Shipping: Direct cooperation with major shipowners ensures lower freight costs and on-time delivery worldwide

Processing and Corrosion Protection Services

Womic Steel offers a complete range of in-house processing services for added value:

- Beveling, threading, and grooving
- CNC machining
- Custom cutting and bending
- Surface pickling and passivation

Our Manufacturing Advantages

Womic Steel excels in the stainless steel pipe industry due to the following strengths:

1. In-house production capacity exceeding 15,000 tons annually for duplex and super duplex pipes
2. Experienced metallurgical and welding engineers
3. On-site testing laboratories certified to global standards
4. Strong long-term partnerships with raw material suppliers, reducing lead time and ensuring consistent quality
5. Advanced cold working and bright annealing lines for precision manufacturing
6. Flexible customization services and fast response to project requirements
