Boiler tubes are essential components used in steam generation systems, industrial boilers, power plants, and heat exchanger equipment. Because these tubes operate under high pressure and high temperature conditions, selecting the correct material is critical for ensuring safe and efficient system performance.
Several international standards define the materials used for boiler tubes, among which ASTM A192, ASTM A210, and ASTM A213 are some of the most widely used specifications. Each of these materials offers different mechanical properties, temperature resistance levels, and application advantages.
Understanding the differences between these materials helps engineers and procurement teams select the most suitable boiler tube material for specific industrial projects.
Womic Steel is a professional boiler tube manufacturer producing seamless boiler tubes according to international standards such as ASTM A192, ASTM A210, ASTM A213, and EN10216 P235GH. With advanced seamless tube manufacturing facilities and strict quality control procedures, Womic Steel supplies reliable boiler tubing solutions for power plants, petrochemical facilities, and industrial heating systems worldwide.
Boiler tubes are generally divided into two main categories: carbon steel boiler tubes and alloy steel boiler tubes. Carbon steel materials are typically used for moderate temperature and pressure applications, while alloy steel materials are used in high temperature environments where improved creep resistance and oxidation resistance are required.
ASTM A192 and ASTM A210 are both carbon steel specifications commonly used in boiler systems, while ASTM A213 includes alloy steel and stainless steel grades designed for higher temperature service.
The following table provides a general overview of these three important boiler tube standards.
|
Standard |
Material Type |
Typical Grades |
Temperature Resistance |
Typical Applications |
| ASTM A192 | Carbon Steel | A192 | Medium | High pressure boilers |
| ASTM A210 | Carbon Steel | Grade A1 / C | Medium to High | Boilers and piping |
| ASTM A213 | Alloy Steel | T11 / T22 / T91 | High to Ultra High | Superheaters and reheaters |
ASTM A192 is a specification for seamless carbon steel boiler tubes designed for high pressure service. These tubes are widely used in industrial boilers and heat exchanger systems where reliable strength and heat transfer performance are required.
The chemical composition of ASTM A192 carbon steel is relatively simple, which provides good weldability and cost efficiency. Because of these characteristics, A192 tubes are widely used in many industrial boiler installations.
Typical chemical composition of ASTM A192 includes the following elements.
|
Element |
Content |
| Carbon | ≤ 0.18% |
| Manganese | 0.27 – 0.63% |
| Phosphorus | ≤ 0.035% |
| Sulfur | ≤ 0.035% |
ASTM A210 is another carbon steel boiler tube specification, but it provides improved mechanical strength compared with ASTM A192. This specification includes Grade A1 and Grade C, which are commonly used in industrial boiler systems.
The higher strength of ASTM A210 makes it suitable for applications where additional pressure resistance is required.
Typical chemical composition of ASTM A210 is shown in the following table.
|
Element |
Grade A1 |
Grade C |
| Carbon | ≤ 0.27% | ≤ 0.35% |
| Manganese | ≤ 0.93% | 0.29 – 1.06% |
| Phosphorus | ≤ 0.035% | ≤ 0.035% |
| Sulfur | ≤ 0.035% | ≤ 0.035% |
Because of the higher carbon content, ASTM A210 tubes provide increased tensile strength compared with ASTM A192.
The following table compares mechanical properties of ASTM A192 and ASTM A210 tubes.
|
Property |
ASTM A192 |
ASTM A210 Grade C |
| Tensile Strength | ≥ 325 MPa | ≥ 485 MPa |
| Yield Strength | ≥ 180 MPa | ≥ 275 MPa |
| Elongation | ≥ 35% | ≥ 30% |
While carbon steel materials are suitable for many boiler applications, modern power plants often operate at extremely high temperatures. In these cases, alloy steel materials are required.
ASTM A213 covers seamless ferritic and austenitic alloy steel tubes used in high temperature service. This specification includes several alloy steel grades such as T11, T22, and T91, which are widely used in power generation equipment.
The addition of alloying elements such as chromium and molybdenum significantly improves the steel’s high temperature strength and resistance to creep deformation.
The following table summarizes typical ASTM A213 alloy steel grades.
|
Grade |
Chromium |
Molybdenum |
Typical Application |
| T11 | ~1.25% | ~0.5% | Boiler tubes |
| T22 | ~2.25% | ~1% | Superheaters |
| T91 | ~9% | ~1% | Ultra supercritical boilers |
Compared with carbon steel boiler tubes, alloy steel materials offer significantly improved performance at elevated temperatures.
To better understand the differences between these materials, the following table summarizes the key advantages of ASTM A192, A210, and A213 tubes.
|
Material |
Main Advantage |
Limitation |
| ASTM A192 | Cost effective | Lower strength |
| ASTM A210 | Higher strength carbon steel | Limited temperature resistance |
| ASTM A213 | Excellent high temperature performance | Higher cost |
Because different sections of a boiler system operate at different temperatures, engineers often use multiple materials within the same system. For example, carbon steel tubes may be used in lower temperature sections of the boiler, while alloy steel tubes are used in superheaters where steam temperatures are significantly higher.
As a professional seamless boiler tube manufacturer, Womic Steel produces a complete range of boiler tubing materials, including ASTM A192 carbon steel tubes, ASTM A210 boiler tubes, and ASTM A213 alloy steel tubes.
These products are manufactured using advanced seamless tube production technology, including hot rolling and cold drawing processes, which ensure excellent dimensional accuracy and consistent mechanical properties.
Strict inspection procedures are also performed during production. Typical quality control processes include:
Ultrasonic testing
Eddy current testing
Hydrostatic pressure testing
Mechanical property testing
Chemical composition analysis
At Womic Steel, all boiler tubes are carefully inspected before shipment to ensure compliance with international standards and customer project specifications.
Boiler tubes produced by Womic Steel are widely used in power plants, refinery heating systems, petrochemical facilities, and industrial steam boilers worldwide.
With extensive experience in seamless steel tube manufacturing, Womic Steel continues to provide reliable boiler tubing solutions for global engineering projects, including seamless boiler tubes, heat exchanger tubes, cold drawn precision tubes, and custom fabricated U bend tubes.
Through advanced manufacturing technology and professional production teams, Womic Steel delivers high performance boiler tube materials designed for demanding industrial applications.
